The Story
This circulator is suitable only for drinking water.
Maintenance-free domestic hot water circulator (glandless pump version) with screwed connection, blocking-current proof synchronous motor according to ECM technology and built-in electronic power control for continuous differential pressure control. Suitable for all domestic hot water systems (+2 to +95 °C).
Standard-equipped with:
- Preselectable control modes for optimum load adjustment:
- Δp-c for constant differential pressure
- Constant speed (3 constant speed stages)
- Constant speed (continuously adjustable)
- LED display for setting the setpoint, displaying current consumption in watts and flow rate in m³/h
- Integrated motor protection
- Automatic deblocking function
- Manual pump venting function for venting the rotor chamber
- Manual restart
- Pump housing made of stainless steel
- Quick electrical connection with Wilo-Connector
- Thermal insulation shell
The Yonos PICO-Z range is a replacement for fixed 3 speed bronze and stainless steel pumps which use older designs and technology and consume considerably more energy.
The addition of an insulation jacket also contributes to reducing heat losses within a hot water system.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
This circulator is suitable only for drinking water.
Maintenance-free domestic hot water circulator (glandless pump version) with screwed connection, blocking-current proof synchronous motor according to ECM technology and built-in electronic power control for continuous differential pressure control. Suitable for all domestic hot water systems (+2 to +95 °C).
Standard-equipped with:
- Preselectable control modes for optimum load adjustment:
- Δp-c for constant differential pressure
- Constant speed (3 constant speed stages)
- Constant speed (continuously adjustable)
- LED display for setting the setpoint, displaying current consumption in watts and flow rate in m³/h
- Integrated motor protection
- Automatic deblocking function
- Manual pump venting function for venting the rotor chamber
- Manual restart
- Pump housing made of stainless steel
- Quick electrical connection with Wilo-Connector
- Thermal insulation shell
The Yonos PICO-Z range is a replacement for fixed 3 speed bronze and stainless steel pumps which use older designs and technology and consume considerably more energy.
The addition of an insulation jacket also contributes to reducing heat losses within a hot water system.
